While working on the integrating Sitecore’s CM’s functionality with third party Digital Asset Management(DAM) system, I came across one interesting issue where I wanted my container applications to run on https.
After integrating the third party DAM with Sitecore CMS, it found out that, while using local website on developer machine, the developer is not able to load the SSO login page. While loading that page below error messages logged in browser’s console.
Access to the WebCrypto API is restricted to secure origins. Compact View requires HTTPS when used outside localhost (for development).
As clearly stated I am not using localhost as host to access my cm and seems like CM needs to be securely severed over https where as we, for local development, use non secure protocol http.
The solution is simple looking form 35,000 feet. Needs CM urls to be serving content over the secure HTTPS protocol. But when actually started digging in details, it is fun and very learning experience.
Performed following steps to achieve this on our local docker development environment.
Open the startup/createcert.ps1 for editing and change following parameter’s default value
$certificatepassword – from b to more secured passowrd string
$dnsNameList – by default the value is *.dev.local. Change this value to match your host pattern. You can specify individual host comma(,) separated.
Alternatively, you can can pass those two as parameter while firing createcert.ps1 command.
3. Open docker-compose.yml file and navigate to cm service and perform following changes:
Add new environment parameter HOST_HEADER and set cm host value to it. If you have multiple host(this is what in my case), specify them semicolon(;) separated list. For example host1.dev.local;host2.dev.local
Under the volumes bind the new volume for folder startup to c:\startup path of container.
Under the port bind the https’s default secure port 443 with the next available container port
The container host port needs to be new port which is not been use by any other services.
Lastly, change the entypoint to the path of startup.ps1 file under the startup folder bound under the volumes in above step for startup folder.
After all above changes to CM service of docker-compose.yml file will look something like below
The QA team, we are working with has raised a very interesting issue while testing newly created data report using Sitecore Poershell Extenstion(SPE).
The data report was executing perfectly but while trying to export the data in any of pre-defined formats offered by SPE, it was not working.
The Sitecore Powershell is allowing export of report data in various industrial standard formats out of the box as listed below:
These formats have option links in the ribbon above but when clicking, none of those producing any output.
First step is to try to reproduce the issue. We tried on all the available environments and it is happening on every environment except for the local environment.
I though the issue may have to do with some missing config or SPE. So, we quickly try to re-install the SPE module on CM with no over-write option for both files and content on Integration Environment. But that does not fix the issue. ☹
So, we started listing what are the major difference from modules and features point of view between local development and other environments on Azure. It turns out that all other environments have exactly the same piece of code, configurations and modules installed except for Federated Authentication using Sitecore Identity Server for CM.
We did quick search over the internet and one of my colleague found out that there is one file which is disabled for SPE which needs to be enable if we are using sitecore 9.1 and higher(we are running 9.3) along with identity server.
The file needs to be enabled is Spe.IdentityServer.config file which is part of the SPE package.
Once package is installed, the file is located at path <<website Root>>\App_Config\Include\Spe\Spe.IdentityServer.config.disabled. The content of this disabled file is as below.
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:role="http://www.sitecore.net/xmlconfig/role/" xmlns:security="http://www.sitecore.net/xmlconfig/security/">
<sitecore role:require="Standalone or ContentManagement" security:require="Sitecore">
<processor type="Sitecore.Owin.Authentication.Pipelines.CookieAuthentication.ValidateIdentity.ValidateSiteNeutralPaths, Sitecore.Owin.Authentication">
<!-- This entry corrects the infinite loop of ExecuteCommand in the SPE Console -->
Tip: The best way to get these config enable in Docker container world, is to leave the above mentioned .disabled file as is. Create new configuration file with above content in Visual Studio solution deploying to z folder under app_config\include on your binding volume path which will be taken care by Sitecore config patching.
While configuring Coveo search on my local development environment using Docker, something got my attention on Coveo’s diagnosis page(<<Sitecore CM Host>>/sitecore modules/Web/Coveo/Admin/CoveoDiagnosticPage.aspx).
This page has all the green ticks except for the one. This is Coveo Search REST Endpoint. See image below for more details.
As usually, I copied the API end point URL and hit in the Browser and it serve the request with no error. It is HTTP-200 response with valid JSON result.
The error in the log file also not giving any lead either.
Coveo.SearchProvider.Applications.BaseVerifier.VerifyComponent(:0) ERROR StateVerifier has encountered an error while verifying the component "Coveo Search REST Endpoint".<br>Exception: Coveo.SearchProvider.Applications.StateVerifierException<br>Message: Failed to obtain resource located at 'http://sicore930.dev.local/coveo/rest/'. See inner exception for details.<br>Source: Coveo.SearchProvider.Applications<br>at Coveo.SearchProvider.Applications.CommonStateVerifier.TryPingRestEndpoint(String p_Endpoint)<br>at Coveo.SearchProvider.Applications.CommonStateVerifier.<>c__DisplayClass11_0.b__0()<br>at Coveo.SearchProvider.Applications.BaseVerifier.VerifyComponent(Func`1 p_VerifyMethod, String p_ComponentName)
I opened docker powershell command for the cm container and tried to request the host from within container.
PS> Docker container ls
Grab the name or container id
PS> Docker exec -it <<container name/id>> cmd
This will open a powershell window connected to the container specified.
Now things are little clear to me. The Coveo diagnosis page is using current host to make REST API request from IIS server running on the container. The container does not have host file entry to reseolve the host url.
So now, I started searching how to make entry in container’s host file??? I was sure, I am not the first person who wanted this kind of stuff.
While setting my local environment for development on Sitecore 9.3 using docker, I came across below issue.
[Win32Exception (0x80004005): The network path was not found]
[SqlException (0x80131904): A network-related or instance-specific error occurred while establishing a connection to SQL Server. The server was not found or was not accessible. Verify that the instance name is correct and that SQL Server is configured to allow remote connections. (provider: Named Pipes Provider, error: 40 - Could not open a connection to SQL Server)]
System.Data.ProviderBase.DbConnectionPool.TryGetConnection(DbConnection owningObject, UInt32 waitForMultipleObjectsTimeout, Boolean allowCreate, Boolean onlyOneCheckConnection, DbConnectionOptions userOptions, DbConnectionInternal& connection) +1341
System.Data.ProviderBase.DbConnectionPool.TryGetConnection(DbConnection owningObject, TaskCompletionSource`1 retry, DbConnectionOptions userOptions, DbConnectionInternal& connection) +159
System.Data.ProviderBase.DbConnectionFactory.TryGetConnection(DbConnection owningConnection, TaskCompletionSource`1 retry, DbConnectionOptions userOptions, DbConnectionInternal oldConnection, DbConnectionInternal& connection) +382
System.Data.ProviderBase.DbConnectionInternal.TryOpenConnectionInternal(DbConnection outerConnection, DbConnectionFactory connectionFactory, TaskCompletionSource`1 retry, DbConnectionOptions userOptions) +307
System.Data.SqlClient.SqlConnection.TryOpenInner(TaskCompletionSource`1 retry) +198
System.Data.SqlClient.SqlConnection.TryOpen(TaskCompletionSource`1 retry) +422
Sitecore.Data.DataProviders.Sql.DataProviderCommand..ctor(IDbCommand command, DataProviderTransaction transaction, Boolean openConnection) +113
Sitecore.Data.DataProviders.NullRetryer.Execute(Func`1 action, Action recover) +293
Sitecore.Data.DataProviders.NullRetryer.Execute(Func`1 action, Action recover) +293
Sitecore.Data.DataProviders.Sql.SqlDataApi.CreateReader(String sql, Object parameters) +281
Sitecore.Data.SqlServer.SqlServerDataProvider.ExecutePreLoadItemDefinitionSql(String sql, Object parameters, SafeDictionary`2 prefetchData) +52
Sitecore.Data.DataProviders.Retryer.ExecuteNoResult(Action action, Action recover) +539
Sitecore.Data.SqlServer.SqlServerDataProvider.LoadInitialItemDefinitions(String condition, Object parameters, SafeDictionary`2 prefetchData) +237
Sitecore.Data.DataProviders.Sql.SqlDataProvider.GetPrefetchData(ID itemId) +62
Unicorn.Data.DataProvider.UnicornSqlServerDataProvider.GetItemDefinition(ID itemId, CallContext context) +242
Sitecore.Data.DataProviders.DataProvider.GetItemDefinition(ID itemID, CallContext context, DataProviderCollection providers) +156
Sitecore.Data.DataSource.GetItemInformation(ID itemID) +88
Sitecore.Data.DataSource.GetItemData(ID itemID, Language language, Version version) +32
Sitecore.Data.Engines.TemplateEngine.GetTemplate(ID templateId) +184
Sitecore.XA.Foundation.SitecoreExtensions.Extensions.DatabaseExtensions.GetContentItemsOfTemplate(Database database, ID templateId) +126
Sitecore.XA.Foundation.Multisite.SiteResolvers.EnvironmentSitesResolver.ResolveAllSites(Database database) +63
Sitecore.Sites.SiteCollection.AddRange(IEnumerable`1 sites) +221
Sitecore.XA.Foundation.Multisite.Pipelines.Initialize.InitSiteManager.Process(PipelineArgs args) +85
(Object , Object ) +9
Sitecore.Pipelines.CorePipeline.Run(PipelineArgs args) +490
Sitecore.Pipelines.DefaultCorePipelineManager.Run(String pipelineName, PipelineArgs args, String pipelineDomain, Boolean failIfNotExists) +236
Sitecore.Pipelines.DefaultCorePipelineManager.Run(String pipelineName, PipelineArgs args, String pipelineDomain) +22
Sitecore.Nexus.Web.HttpModule.Init(HttpApplication app) +1165
System.Web.HttpApplication.RegisterEventSubscriptionsWithIIS(IntPtr appContext, HttpContext context, MethodInfo handlers) +584
System.Web.HttpApplication.InitSpecial(HttpApplicationState state, MethodInfo handlers, IntPtr appContext, HttpContext context) +168
System.Web.HttpApplicationFactory.GetSpecialApplicationInstance(IntPtr appContext, HttpContext context) +277
System.Web.Hosting.PipelineRuntime.InitializeApplication(IntPtr appContext) +369
[HttpException (0x80004005): A network-related or instance-specific error occurred while establishing a connection to SQL Server. The server was not found or was not accessible. Verify that the instance name is correct and that SQL Server is configured to allow remote connections. (provider: Named Pipes Provider, error: 40 - Could not open a connection to SQL Server)]
System.Web.HttpRuntime.FirstRequestInit(HttpContext context) +532
System.Web.HttpRuntime.EnsureFirstRequestInit(HttpContext context) +111
System.Web.HttpRuntime.ProcessRequestNotificationPrivate(IIS7WorkerRequest wr, HttpContext context) +724
The error speaks itself, that the CM and/or CD was not able to connect to underlying SQL server. SO, I immediately opens the SSMS and try to connect to my SQL server running as container on my local and I am successfully able to connect both using IP address as well as using alias(in my case it’s sql).
So what’s the issue??? When I am able to connect to SQL server running in container using outside of the Docker created network than why my CM and/or CD instance is not able to connect to it within the same network???
I check inward and outward binding ports setting in docker-compose.yml file for SQL service. Double check connection strings for server name, user name and password and that all looks correct.
Thanks to one of my colleague, who points out my docker-compose file was missing hostname for SQL server service.
I have added them to my docker-compose.yml for SQL, SOLR and XCONNECT and happy days.
